Getting Started
Create your account
Setting Up Room Defaults
Click Here to access and change the default Room Settings
Supply Defaults
Product Supply Method:
- Choose Flat-Packed or Assembled.
- Selecting Assembled automatically includes hardware.
- Selecting Flat-Packed lets you choose whether hardware is supplied.
Hardware Inclusions:
- For Flat-Packed jobs, pick Supply Hardware or Do Not Supply Hardware.
- Panels are drilled to your specs either way.
Adjustable Legs:
- Tick the box if you want drilling for adjustable legs.
Hardware Default
Select the default hardware that will apply as products are added to the job (Note: Changes can be made per cabinet, as they are added.)
- Default Hinge Style: e.g. Blum Inserta Soft Close
- Default Drawer Style: e.g. DTC EE Smooth
- Set Rail/Top Style: e.g. Rail on Edge or Solid Top
Exterior Material Defaults
Select the colour and finish for doors and external panels.
- Use the search bar or colour browser to find the brand, finish or colour name of the material.
- After selecting material edge colour updates to match automatically.
- If you want to select a contrasting edge, search and select one in the edge field.
- For wood grain materials, use the checkbox to set the grain direction.
2 Pac Paint (Flat Panel, Shaker, VGroove etc):
- Select Paint Grade MDF Satin in the material field
- Select Door type/profile e.g. Shaker
Carcass-Only:
- If you do not want to order doors, select the non supply option for Material, Edge and Door Fields
Internal Material Defaults
Choose the carcase materials the same way you select exterior materials.
- This will typically be 16mm HMR Texture Type Carcase in material field to select white or black carcase or choose Shop Materials in the colour browser
Coloured Internals:
- All available colours are able to be selected as the default for internals
- e.g. for a wardrobe with all open shelving.
Product Size Defaults (Optional)
This section lets you pre set the standard dimensions of products added to the job. Note: This step is optional as each product can be resized individually later
- Three fully customisable pre-set profiles are available by default
- Visual diagram to easily adjust the default size of Base, Upper and Tall Cabinets added to the job.
Save time by setting up the rooms defaults
- Click the visual diagram to change the size in field to -
- Set the Kick height and shelf setback
- Set the height and depth of Base, Upper and Tall Cabinets
Save even more time. Create your own Default Profiles:
- To Create your own default profiles
- Go to your account settings -> Product Defaults -> Product Sizes Tab
Gap Size Defaults (Optional)
This section lets you define the default door and drawer gaps for your job. Note: This step is optional as each cabinet can have individual door gaps assigned
- Like product size defaults, pre-set profiles for door gaps are available by default and are fully customisable to suit your needs.
- Visual diagram to help see exactly which side the gaps and margins affect.
Gaps:
- Left and Right gaps set the gap distance in from the edge of a cabinet.
- Door and Drawer gaps Set the distance between pairs of doors and between drawer fronts in a bank.
Margins:
- Margins allow you to adjust the gap at the top and bottom of the cabinet
- Base Cabinets and Upper cabinets can have different default margins.
- For example, a Base Cabinet Bottom Margin of 0 means the door sits flush with the bottom of the carcase.
Overhead Drop Door Finger pull:
To create a drop door finger pull on upper cabinets.
- Add a negative margin in the Upper Bottom Margin field.
- e.g. –30mm will extend the door 30mm below the carcase.
- This will apply automatically to every upper cabinet you add to the room.
